Versions
| Code | Description |
|---|---|
| 74620006 | single-phase 230V with Acrux AB inverter control unit |
| 74620004 | three-phase 400V with Meteor AB control unit |
| 74620002 | three-phase 230V without control unit |
| 74620003 | three-phase 400V without control unit |
Features
Adjustable speeds up to 0,7 m/s (57 RPM)
Emergency operation always-engaged with crank or chain
Drastically reduced side installation dimensions to 10 cm with easy maintenance
For shutters up to 354 kg
Mechanical and electronic limit switch
Automatic and deadman control, with dry contact switches, integrated in the board
The on-board control panels provide power supply and control logic for photocells and/or 12 Vdc barriers.
Technical data
Emergency operation with hand crank
Emergency operation with hand chain
Mechanical limit switch with safety microswitches
Electronic limit switch with absolute multi-turn encoder
| Power supply |
1~230 V
3~400 V
|
| Output torque on motor | 180 Nm |
| Output torque on shaft | 180 Nm |
| Max lift capacity | 354 Kg |
| Frequency | 50/60 Hz |
| Consumption |
3,6 A
2 A
|
| Power | 1100 W |
| Protection Category | IP 54 |
| Output speed on motor | 31,5 RPM |
| Output speed on shaft | 31,5 RPM |
| Ø Installation shaft | 25 / 25,4 (1”) / 30 mm |
